Manual Transfer 8 Tank Ultrasonic Cleaning Machine With Oscillation Mechanism

Name: Manual Transfer 8 Tank Ultrasonic Cleaning Machine With Oscillation Mechanism
Brand: Hongshun
Price: 4 USD

Brand Name : Hongshun

Model Number : HS-8050SW

Certification : CCC/CE

Place of Origin : Guangdong

MOQ : 1 set

Price : $4,000 to $8,000

Payment Terms : L/C,T/T

Supply Ability : 5 sets/month

Delivery Time : 20 days

Packaging Details : film

Applications : metal parts

Total ultrasonic power : 7.5 KW

Equipment capacity : 3-5 minutes / basket

Power supply : 380±10%/50HZ

Heating temperature : 80℃

Ultrasonic frequency : 28 KHZ

Contact Now

Manual Transfer 8 Tanks Ultrasonic Cleaning Machine With Oscillation Mechanism

Ultrasonic Cleaning Machine Overview:

This manual transfer 8-tank ultrasonic cleaning machine features an oscillation mechanism to enhance cleaning efficiency. The 8-tank system (pre-soak, ultrasonic wash, 3-stage rinse, passivation, drying) caters to complex cleaning needs. With adjustable frequencies (28-40kHz), it adapts to various metal parts.

The oscillation mechanism agitates parts, dislodging stubborn contaminants like oil, wax, and debris. Each tank has temperature control (30-80℃), optimizing detergent performance. Manual transfer allows careful handling of delicate components.

Ideal for precision parts in aerospace, automotive, and electronics industries—such as gears, connectors, and small hardware. The final drying tank with hot air ensures <0.1% moisture, preparing parts for assembly or coating. Boosts productivity by 40% vs single-tank cleaners.

Process configuration table of 8 Tanks Ultrasonic Cleaning Machine :

order	process flow	Ultrasonic power	service substance	wash time	working temperature
1	loading
2	Ultrasonic cleaning with wash agent	1.5KW 28KHZ	Cleaner + municipal water	2-5min	50-60 degrees
3	Ultrasonic cleaning with wash agent	1.5KW 28KHZ	Cleaner + municipal water	2-5min	50-60 degrees
4	Ultrasonic cleaning with wash agent	1.5KW 28KHZ	Cleaner + municipal water	2-5min	50-60 degrees
5	Ultrasonic cleaning with wash agent	1.5KW 28KHZ	Cleaner + municipal water	3-5min	50-60 degrees
6	City water rinsing		City water	2-3 min	RT
7	City water rinsing		City water	2-3 min	RT
8	City water rinsing		City water	2-3 min	RT
9	The ultrasonic water rinsing	1.5KW 28KHZ	City water	2-5min	50-60 degrees

Main technical parameters of the Ultrasonic Cleaning Line:

Total ultrasonic power	7.5KW (a total of 5 ultrasonic tanks, each 1.5KW)
Ultrasonic frequency	28KHz.
Maximum total power of the equipment	20 KW.
Power supply	380VAC, 3p5w,50HZ.
Machine size	(length x width x height) approximately according to the drawing or physical object

For a complete technical solution Of Ultrasonic Cleaning Line, please contact me. We will customize the design based on your product technical requirements and factory layout.
